Item

Parameters

Print parameters

Printing Method

Thermal Line

Printing width

72mm

Resolution

576 Dots/Line or 512 Dots/Line（8dots/mm，203dpi）

Print speed

160-220mm/Second(MAX)

Interface

USB,Internet,Bluetooth,WIFI(Interface combination, pls contact manufacture to confirm)

Line Spacing

3.75mm（Can adjust line spacing by command）

Line No.

FontA-48Lines/FontB-64Lines/Simple,traditional Chinese-24lines

Character

standard GB18030 simplified / BIG5 traditional Chinese Fonts(Japanese and Korean optional)

Character Size

ANK character：Font A：1.5×3.0mm（12×24 dots）
Font B：1.1×2.1mm（9×17 dots）
Simplified/Traditional Chinese：3.0×3.0mm(24×24 dots）

Bar code Character

Extended character set

PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian

/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)

Bar code

1Dbarcode:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
2D barcode：QRCODE

Graphics printing

Graphics printing

Supports bitmap download and print

Paper

Type

Thermal

Width

79.5±0.5mm

Diameter

≤80mm

Feed method

Easy feed(Clamshell feed)

Print commands

Commands

ESC/POS

Power

Power Adaptor

Input：AC 100V-240V,50-60Hz
Output：DC 12V/2A

Cash Drawer Output

DC 12V/1A

Buffer

NV Flash

256K bytes

physical characteristics

Weight

0.9KG

Dimension

185*133*133(MM)

environment

Working

Temp：5 ~ 45℃， Humidity：10 ~ 80%

Storage

Temp：-10 ~ 50℃ ，Humidity：10 ~ 90%（No dew）

Reliability parameter

Print Head Life

100KM（print density≤12.5）

Cutter Life

1000,000times

Software

Driver

Android,IOS,Linux,Windows
