Technical Specifications

Electrical Characteristics

Interface Supported

USB HID KEYBOARD/USB VCP

Input Voltage

DC 5V±5%

Current

Max:335mA

Optical Characteristics

Image Sensor

CMOS Array Sensor

Sensor Resolution

640 X 480 Pixels

Light Aimer

617nm LED

Indication

Buzzer & LED

Trigger

Auto-sense, Button

Decoding speed

60FPS

Performance Characteristics

Scanning Angle

Pitch angle:±55°;Skew angle:±55°;Tilt angle:±360°

Field of View

43° H),33° V)

Min Resolution

1D≥4mil, 2D≥5mil

Min .PCS value

〉20% UPC/EAN 13（13mil）

Language

Multiple Languages

Data Edition

Support for custom data output

Decode Capability

1D: Codabar,Code39,Interleaved2of5,NEC2of5, Code93, Straight 2 of 5 Industial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code128, GS1-128, UPC-A, UPC-E0, UPC-E1, EAN/JAN-13, EAN/JAN-8, MSI, GS1-DataBar Omnidirectional,GS1 DataBar Limited, GS1 DataBar Expanded, China Post(Hong Kong 2 of 5),GS1 Composite Codes,Codeblock A,Codeblock F,Code 32,EAN/JAN-8, ISSN, ISBN

2D：PDF417, QR Code, Data Matrix, Aztec code, HanXin code, Maxi Code, Micro PDF417, GS1 Composite

Physical Characteristics

Dimensions

85mm*85mm*140mm(L*W*H)

Weight

370g

Indicator

Beeper, LED

Environmental Characteristics

Temperature

-20°Ã¢ÂˆÂ½60°C (operation)

-30°Ã¢ÂˆÂ½70°C (storage)

Humidity

Relative humidity: 5% to 95% (no condensation)

Shock Drop Test

1.5m drop onto concrete surface

Symbology

Resolution

Nearest

Farthest

Code 39

5mil

10mm

90mm

Code 39

13mil

0mm

175mm

UPC-A

3.34mil

10mm

170mm

QR

20mil

0mm

130mm

QR

30mil

0mm

180mm

Pay Code（QR 3*3cm）

-

10mm

320mm

Pay Code（QR 2.3*2.3cm）

-

0mm

260mm
